NEW BUNGALOW SALES BUBBLE V2 REINFORCED SERIES 4 METERS
Original price was: £6,700.00.£6,200.00Current price is: £6,200.00.
Technical Specifications
DIMENSIONS
External height: 252 cm
Internal height: 220 cm
Length: 409 cm
Width: 242 cm
FRAME
Material: Galvanized and lacquered steel
Colour: Anthracite grey RAL 7016
Thickness: 2 mm
Roof height: 200 mm
Base height: 160 mm
WALLS AND ROOF
Material: Sandwich panels
Insulation: Rigid polyurethane foam
Wall thickness: 50 mm
Roof thickness: 40 mm
Roof covering: Galvanized steel sheet with Greek waves
Wall colour: Light grey RAL 9002
FLOOR
Structure: Water-resistant chipboard panels
Thickness: 18 mm
Finish: PVC imitation parquet with black skirting boards
Insulation: 50 mm thick glass wool underfloor insulation on protective steel plates
JOINERY
Material: Lacquered anthracite grey RAL 7016 aluminium
Door(s): 1 fully glazed entrance door, dimensions 104 x 220 cm (90 cm passage width), clear laminated safety glazing 4+4 mm thick.
Window(s): 1 fixed French window, dimensions 204 x 220 cm, clear laminated safety glazing 4+4 mm thick, and 1 fixed French window, dimensions 184 x 220 cm, clear laminated safety glazing 4+4 mm thick
Shutter(s): Aluminium roller shutters on post and French windows, anthracite grey RAL 7016
ELECTRICITY
Lighting: 1 LED neon light + 1 switch next to the door
Sockets: 2 power outlets
Heating: 1 convector 1500 W
Panel: 1 panel including differential circuit breaker and circuit breakers (maximum 6 kW)
Connection: 1 external connection box
Optional Features
Free colour choices for the frame: white RAL 9010, light grey RAL 9002, or anthracite grey RAL 7016
Other colours available for panels, frame, or joinery upon request
Ceiling height: 2.40 m, door height: 2.20 m
Base on skids (2 IPE 16 cm beams)
Integrated WC corner with toilet + washbasin + door + partitions (hot water available at the sink as an option)
Integrated shower corner (with hot water) + door + partitions
4 rainwater downpipes
Air Conditioning Options
- Reversible air conditioner 2300 W UNICO R10
- Window air conditioner cooling only 12000 BTU
- Mobile air conditioner SHINY 12 Reversible R290 3.5 KW + window kit
Flooring Options
- LED panels instead of neon lights
- Additional semi-glazed door, full door, or fully glazed door
- Additional semi-glazed, full door, or fully glazed door
- Additional window, French window, snack window, or window with hatch and hygienic screen
- Aluminium or PVC roller shutters, specific colours available
- Wood-cement floor 16 mm thick instead of chipboard (essential if the bungalow is not raised by a few cm with blocks or wedges, also for humid environments) with a load-bearing capacity of 400 kg/m²
- Phenolic wood floor 18 mm thick instead of chipboard, with a load-bearing capacity of 500 kg/m²
- High-traffic PVC flooring instead of PVC imitation parquet or tile flooring
- Smooth panels, food-grade panels, rock wool panels, or fireproof panels
- Additional sockets or RJ45 sockets
- Options to add a kitchenette
- Sink on unit 80×60 cm with cold water
- Sink on unit 80×60 cm with hot water
- Sink on unit + hot water + 2 cooking plates + fridge
Our 4-Meter Sales Bubble Bungalow V2 is a module with two fully glazed facades, designed to meet the needs of sales offices for various activities: real estate developers, vehicle sellers, marble businesses, freelancers working from home, professionals, and more.
New 4-Meter Sales Bubble Bungalow V2
The Sales Bubble Bungalow offers you a comfortable and aesthetic office or sales space at an unbeatable price and delivery time compared to traditional construction solutions. We have standardized 4 sales bubbles in different sizes and with various levels of options.
Our 4-Meter Sales Bubble V2 comes as standard in our “Reinforced” series.
The “Reinforced” series bungalows feature a reinforced structure, as well as improved thermal and acoustic insulation (thick insulation and double glazing). They provide better comfort compared to the standard series, making them more suitable for use as office spaces, for example.
The Sales Bubble V2 offers several additional features compared to the V1: Aluminium joinery in RAL 7016 Anthracite Grey, fully glazed entrance door, and floor insulation.
If you want the same module with the strongest structure available in our range or the highest-performing thermal and acoustic insulation, you can request a quote for this bungalow from our “Isoplus” series.
Our “Sales Bubble V2” bungalow has a manufacturing and delivery lead time of 8 weeks. For a faster delivery with a similar configuration, you should consider our 6-Meter Sales Bubble Bungalow V2 (available only in 6 meters).
